Overview
Designed for enduring outdoor applications, our Powder Coated Aluminium Alloy Tube Pipes 6063 T5 offer vibrant aesthetics and superior weather resistance, ideal for outdoor furniture, fencing, and architectural structures. Crafted from 6063-T5 aluminum with electrostatic powder coating, these pipes feature high-impact resistance, fade-proof finishes, and customizable dimensions, redefining durability in outdoor environments.
Features
Premium Powder Coating
Finish Quality: 70-100μm polyester powder coating (AAMA 2604 compliant), passing 2000h salt spray (ASTM B117) and 5000h UV exposure (ΔE ≤3), available in 200+ RAL colors and metallic effects.
Adhesion: Cross-cut test (ISO 2409) Class 0, ensuring zero film detachment after 10mm mandrel bend (ASTM D3359-09).
Mechanical Performance
Alloy Strength: 6063-T5 (yield strength 215 MPa, elongation 12%) for structural applications, supporting loads up to 80kg/m (calculated per EN 1999-1-1).
Seamless Extrusion: Hollow profiles (round, square, rectangular) with wall thickness 1.5-6mm, minimizing material waste (95% extrusion yield).
Dimensional Precision
Tolerance Control: OD/width tolerance ±0.3mm, wall thickness ±0.15mm (ISO 2768-1 medium class), ensuring compatibility with standard connectors (e.g., Kepla, Hawa).
Length Options: 1-12m standard lengths, with custom cutting (±1mm accuracy) for on-site installation efficiency.
Low Maintenance
Corrosion Resistance: Powder coating acts as a moisture barrier, eliminating the need for annual repainting—maintenance costs 80% lower than painted steel over 10 years.
Cleanability: Smooth surface (Ra ≤3.2μm) resists dirt accumulation, cleanable with water pressure (≤100 bar) without finish damage.
Application
Outdoor Furniture: Frames for patio chairs, tables, and umbrellas, with UV-stabilized finishes ideal for tropical climates (ISO 4892-2 compliant).
Fencing & Railings: Decorative and security fencing in residential and commercial properties, with impact resistance (IK06 rating, 10J energy) for pedestrian areas.
Architectural Canopies: Lightweight supports for outdoor shading structures, compliant with EN 1090-1 EXC2 structural integrity standards.
Why Choose Us
Finish Longevity
AAMA 2604-certified coating ensures 10-year fade warranty, outperforming generic powder coatings by 50% in harsh sun exposure (e.g., Arizona desert testing).
Customization Depth
Offer embossed textures, wood-grain effects, and anti-graffiti coatings (MOQ 500 meters), supported by in-house paint lab for color matching.
Lean Manufacturing
Automated powder coating lines (throughput 5000 meters/day) with 98% first-pass yield, reducing lead time to 15 days for custom color orders.
Environmental Responsibility
Zero-VOC powder coatings (EPA SNAP compliant) and 95% recycled packaging, aligning with LEED v4 and BREEAM sustainability criteria.
Alloy |
Si |
Mg |
Fe |
Cu |
Mn |
Zn |
Cr |
Ti |
1050 |
0.25 |
0.05 |
<0.40 |
<0.05 |
<0.05 |
<0.05 |
- |
<0.03 |
3003 |
0.6 |
- |
0.7 |
0.05 -0.20 |
1.0-1.5 |
0.10 |
- |
- |
5052 |
0.25 |
2.2-2.8 |
0.4 |
0.1 |
0.1 |
0.10 |
0.15-0.35 |
- |
5083 |
0.4 |
4.0-4.9 |
0.4 |
0.1 |
0.4-1.0 |
0.25 |
0.05-0.25 |
0.15 |
6005 |
0.6-0.9 |
0.4-0.6 |
<0.35 |
<0.1 |
<0.1 |
<0.1 |
<0.1 |
<0.1 |
6061 |
0.4-0.8 |
0.8-1.2 |
<0.70 |
0.15-0.4 |
<0.15 |
<0.25 |
0.04-0.35 |
<0.05 |
6063 |
0.2-0.6 |
0.45-0.9 |
<0.35 |
<0.1 |
<0.1 |
<0.1 |
<0.1 |
<0.1 |
6082 |
0.7-1.3 |
0.6-1.2 |
<0.50 |
<0.1 |
0.4-1.0 |
<0.2 |
<0.25 |
<0.10 |
