Aluminum square tubes are widely used in construction, manufacturing, automotive, aerospace, and architectural design due to their lightweight, corrosion resistance, and versatility. Among the various aluminum alloys available, 6061 and 6063 stand out as two of the most common choices. Both are widely used in extruded aluminum tubes, but understanding their differences is crucial to choosing the right material for your application.
In this in-depth guide, we compare 6061 and 6063 aluminum square tubes across multiple categories—strength, weldability, thermal conductivity, mechanical properties, and more. We’ll also discuss real-world applications and provide expert tips on how to choose the most suitable alloy for your project. Whether you’re a buyer, engineer, or designer, this article will help you make a data-driven decision.
Both 6061 and 6063 are part of the 6000 series aluminum alloys, which are known for their good corrosion resistance, excellent machinability, and moderate-to-high strength. They are commonly used in extruded forms, such as aluminum square tubes, round tubes, and rectangular profiles.
6061 Aluminum is a structural alloy with higher strength and toughness. It is often used in heavy-duty applications like aerospace, automotive frames, and industrial equipment.
6063 Aluminum is an architectural alloy praised for its excellent surface finish and formability. It’s commonly used in window frames, railings, and decorative structures.
Although both alloys are used in making high-quality aluminum tubes, their properties and performance vary significantly depending on the intended use.
To give you a quick overview, here is a comparison table of the key differences between 6061 and 6063 aluminum square tubes:
| Property | 6061 Aluminum Square Tube | 6063 Aluminum Square Tube |
|---|---|---|
| Tensile Strength | ~290 MPa (42,000 psi) | ~190 MPa (28,000 psi) |
| Yield Strength | ~240 MPa (35,000 psi) | ~160 MPa (23,000 psi) |
| Corrosion Resistance | Good | Excellent |
| Surface Finish | Fair | Very Smooth |
| Weldability | Good | Excellent |
| Formability/Bending | Moderate | Better |
| Thermal Conductivity | Slightly lower | Slightly higher |
| Common Tempers | 6061-T6 | 6063-T5 |
| Typical Applications | Structural, load-bearing parts | Architectural, decorative parts |
This table highlights how 6061 vs 6063 aluminum strength and formability differ significantly, and why understanding these differences is essential.
When it comes to strength, 6061 aluminum square tubes are the clear winner. They offer higher tensile and yield strength, making them ideal for structural and load-bearing applications.
6061: Its higher magnesium and silicon content gives it better mechanical properties. It is preferred in applications that require strength over appearance.
6063: Has lower strength but superior surface quality, suitable for applications where appearance matters more than mechanical force.
| Mechanical Property | 6061-T6 | 6063-T5 |
|---|---|---|
| Tensile Strength | ~290 MPa | ~190 MPa |
| Yield Strength | ~240 MPa | ~160 MPa |
| Elongation (%) | 10–17% | 12–18% |
| Hardness (Brinell) | 95 | 73 |
If your project involves pressure, heavy loads, or high-impact environments, 6061 aluminum tubes are more suitable.
Welding is a critical consideration in many aluminum tube applications. Both alloys can be welded, but with slight differences in performance.
6061 is weldable but may require post-weld heat treatment to restore strength. It is more prone to cracking if not handled correctly.
6063 offers better weldability and requires less post-weld treatment, making it ideal for architectural and decorative applications where welding is common.
6063 aluminum square tubes are easier to bend and form due to their lower strength and higher ductility. If your project involves intricate shapes, curves, or continuous forming, 6063 is the better option.
Heat transfer and chemical resistance can impact performance in certain environments, especially in electronics, HVAC, and marine applications.
6061: ~167 W/m·K
6063: ~201 W/m·K
6063 aluminum has slightly higher thermal conductivity, which can be advantageous in heat exchange or thermal management systems.
| Element | 6061 (%) | 6063 (%) |
|---|---|---|
| Magnesium (Mg) | 0.8–1.2 | 0.45–0.9 |
| Silicon (Si) | 0.4–0.8 | 0.2–0.6 |
| Iron (Fe) | ≤0.7 | ≤0.35 |
| Copper (Cu) | 0.15–0.4 | ≤0.1 |
| Chromium (Cr) | 0.04–0.35 | ≤0.1 |
6061 contains more alloying elements, contributing to its strength. 6063's simpler chemical profile improves its surface finish and corrosion resistance.
Heat treatment affects the hardness, strength, and performance of aluminum tubes.
Solution heat-treated and artificially aged.
Offers the highest strength among standard 6061 tempers.
Suitable for structural components and high-performance systems.
Cooled from extrusion and artificially aged.
Offers moderate strength with excellent surface finish.
Commonly used in anodized architectural products.
If your project demands strength and durability, 6061-T6 is the better choice. For decorative, aesthetic, or lightweight use, 6063-T5 offers better value.
Visually, distinguishing between the two can be difficult. Here are some practical methods:
Surface Finish: 6063 usually has a smoother finish than 6061.
Hardness Test: 6061 feels harder and is more difficult to scratch.
Labeling: Most suppliers label their aluminum tubes with alloy codes.
Supplier Certification: Reputable suppliers like Guangyuan provide full material certification.
If in doubt, request a Material Test Report (MTR) or use X-ray fluorescence (XRF) analyzers for accurate identification.
Understanding application context helps in selecting the right alloy. Below are typical uses for each:
Aerospace structures
Bike frames
Automotive chassis
Structural support beams
Heavy-duty industrial equipment
Window and door frames
Architectural railings
Display systems
Lighting enclosures
Decorative trims
If your project prioritizes strength, choose 6061 aluminum tubes. For appearance and ease of fabrication, 6063 is the better fit.
Wuxi Gold Guangyuan Metal Products Factory specializes in high-quality aluminum tubes for industrial and commercial use. Their aluminum square tubing is available in both 6061 and 6063 alloys and offers:
Tight dimensional tolerances
Customized length and wall thickness
Full certification and traceability
Non-magnetic materials for electronics and medical applications
Q1: Which aluminum tube is stronger, 6061 or 6063?
A1: 6061 is significantly stronger than 6063, making it better for structural and load-bearing applications.
Q2: Can I weld 6061 and 6063 aluminum tubes together?
A2: Yes, but ensure proper welding techniques and compatible filler materials are used to avoid cracking or weak joints.
Q3: Is 6063 aluminum better for bending than 6061?
A3: Yes, 6063 is more ductile and easier to form, making it ideal for curved or complex shapes.
Q4: What does 6061-T6 mean?
A4: It refers to a heat-treated condition that enhances the strength of 6061 aluminum through solution treatment and artificial aging.
Q5: Can I use 6063 aluminum tubes in structural applications?
A5: While 6063 can be used structurally, it’s usually not recommended for high-load scenarios. 6061 is the better option for strength.
Q6: How do I identify aluminum tube alloy types?
A6: Check supplier labels, request certification, or use spectrometry or hardness testing to distinguish between 6061 and 6063.
Q7: Where can I buy 6061 and 6063 aluminum square tubes?
A7: Guangyuan offers a wide selection of aluminum tubes, including both 6061 and 6063 square tubing, with global shipping and OEM customization.
Both 6061 and 6063 aluminum square tubes are excellent materials, but they serve different purposes. If your project demands strength, durability, and structural support, go with 6061. If you need a smooth, attractive finish with great weldability and formability, 6063 is your best bet.
By understanding the mechanical properties, chemical composition, welding behavior, and application suitability of both alloys, you can make the right choice for your project and ensure long-term performance.
