What Is Material Of Compressed Air Aluminum Tube?
You are here: Home » News » Industry news » What Is Material Of Compressed Air Aluminum Tube?

What Is Material Of Compressed Air Aluminum Tube?

Views:9     Author:Site Editor     Publish Time: 2019-06-18      Origin:Site


Speaking of aluminum tube, we have to think of its application in the air compressor, aluminum tube can even be said to be the soul of the air compressor. How much do you know about the various materials of aluminum tubes that have different advantages and characteristics?


Black Drilling Mandrel Bends Aluminium Tube


Here is the content list:


  • Aluminum Tube Of 6063

  • Aluminum Tube Of 6005

  • Aluminum Tube Of 6061

  • Effect of Aluminum Tube On Air Compressor


Aluminum Tube Of 6063


Aluminum pipe is made of pure aluminum or aluminum alloy by extrusion processing along its longitudinal length of the hollow metal tubular material, there can be one or more closed through the hole, wall thickness, cross section uniform, with a straight line or into a roll delivery. Aluminum tube is widely used in automobile, ship, aerospace, aviation, electrical appliances, agriculture, electromechanical, household and other industries.


6063 alloy aluminum tubes are widely used in the frame of building aluminum doors, windows and curtain walls. In order to ensure that doors, curtain walls have high wind pressure resistance, assembly performance, corrosion resistance and decorative performance, the requirements for the comprehensive performance of aluminum alloy profiles are far higher than the standards for industrial profiles. Needless to say, our aluminum tubes possess all the above advantages.


The 6063-alloy aluminum tube used in our compressed air contains 0.2-0.6 Si, 0.35Fe, 0.1Cu,0.1 Mn, 0.45-0.9Mg, 0.1Cr,0.1 Zn, 0.1Ti, and the impurity is 0.15.


Aluminum Tube Of 6005


6005 belongs to al-mg alloy, widely used, especially in the construction industry. It is the most promising alloy, with good corrosion resistance, excellent welding performance, good cold working performance and moderate strength. It is one of the most widely used anti-rust aluminum tube, this alloy has high strength, especially with the anti-fatigue strength, with plastic and corrosion resistance, not heat treatment strengthening, in the semi-cold hardening of plastic is still good, cold hardening of plastic is low, corrosion resistance, good welding, poor cutting performance, polishing. It is mainly used for demanding high plasticity and good weldability, like compressed air and solar panels.


The 6005-alloy aluminum tube used in our compressed air contains 0.6-0.9 Si, 0.35Fe, 0.1 Cu, 0.1 Mn, 0.4-0.6Mg, 0.1 Cr, 0.1 Zn, 0.1 Ti, and the impurity is 0.15.


Aluminum Tube Of 6061


6061 - T651 is the main alloy, 6061 aluminum alloy is a pre-stretching heat treatment process of high quality aluminum pipes, its strength is not compared with 2 XXX or 7 XXX department system, but its more magnesium, silicon alloy properties, has the excellent processing performance, excellent welding characteristics and electroplating, good corrosion resistance, high toughness and processing after deformation, dense material without defects and easy polishing, coloring film easily, good features such as oxidation excellent results.


The 6061-alloy aluminum tube used in our compressed air contains 0.4-0.8 Si, 0.70 Fe, 0.15-0.4 Cu, 0.15 Mn, 0.8-1.2 Mg, 0.04-0.35 Cr, 0.25 Zn, 0.15 Ti, and the impurity is 0.15.


Effect of Aluminum Tube On Air Compressor


  • Lower energy costs


The air compressor energy-saving pipeline has a smooth aluminum internal surface, using aluminum tube can provide more airflow, lower pressure drops, leading to a significant reduction in operating costs, and ensure that the pressure drop over time and reduce energy wave costs. Built-in O-rings ensures tight fit. By reducing the pressure drop by 1bar through using aluminum tubes.


  • Durability


Air compressor energy-saving aluminum tube system has corrosion resistance, resistance to mechanical vibration, resistance to fire, heat vibration ability, can withstand the harsh outdoor day gas conditions. Thanks to its stable high quality clean air, the aluminum tube system ensures long service life of the equipment and prolongs the life of the filter.


  • Flexibility


The energy-saving aluminum tube for the air compressor can be readily installed with a quick steering device to construct additional diverters as it is connected to the side, thereby eliminating the risk of condensate pollution. Air compressor energy-saving aluminum tube can be installed on the wall or ceiling, the series of accessories can be made, you can customize the compressed air system and aluminum tube according to your specific production needs.


  • Leakproof


The aluminum tube of air compressor is designed to prevent corrosion, ensure no leakage and eliminate energy waste.



The above is the classification of aluminum tube and its application in the air compressor, I hope it will be helpful you. We are a professional manufacturer of various aluminum tube and machining parts in China, with 25 years’ experience in design and production. If you want to buy aluminum tubes, you will never regret to cooperate with us.
